Запчасти Komatsu WB91R-5 РЫЧАГ УПРАВЛ-Я ПОДАЧЕЙ ТОПЛИВА (/) СИСТЕМА УПРАВЛЕНИЯ

\0

42N-54-14400

FUEL LEVER, ASSY.

1

42N-54-14410

SUPPORT

2

42N-54-14430

PIN

3

37A-09-63171

SPRING

4

42N-54-14440

WASHER

5

01640-21426

WASHER

6

01598-11415

NUT, STOP

7

42N-54-14420

FUEL LEVER

8

42N-54-14460

KNOB

9

42N-54-17240

SCREW

10

42N-54-14450

BOOT

11

01252-80820

SCREW

12

01598-00809

NUT, STOP

13

42N-54-17110

SCREW

14

42N-43-11440

CABLE

15

37A-09-61019

PIN

16

42N-54-14570

PAWL

17

01643-11032

WASHER

18

42N-54-17270

NUT

19

42N-54-14490

SHAFT

20

42N-54-14520

BEARING

21

42N-54-14510

SUPPORT

22

42N-54-15960

SCREW

\22

42N-54-14500

TIE-ROD, ASSY.

23

37A-09-5Z019

FORK

24

01580-10605

NUT

25

42N-54-14530

TIE-ROD

26

42N-54-14560

BUSHING

27

01580-10605

NUT

28

21D-09-15170

SCREW

29

01643-11445

WASHER

30

01643-10823

WASHER

31

21D-09-21720

NUT

32

01598-00809

NUT, STOP

33

42N-54-14470

LEVER

34

37B-09-2C006

SPRING

35

395-56-11H60

RING

36

395-56-11H50

BEARING

37

42N-54-14480

LEVER

38

01252-70845

SCREW

39

42N-54-15620

PEDAL

40

04064-01410

RING, SNAP

41

42N-54-14580

STOPPER

42

01580-10806

NUT

43

42N-54-19870

GROMMET
