Запчасти Komatsu WB91R-2 ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ

\0

871070052

ASPIRATED ENGINE

1

YM129004-55610

BRACKET

2

YM123907-55801

FILTER

3

YM26106-080302

BOLT

4

YM119160-59010

PIPE ASSY

5

YM129950-59221

PROTECTION

6

YM105025-59530

PIPE

7

YM129957-59040

PIPE

8

YM119560-59110

PROTECTION

9

YM129335-59090

PIPE

10

YM23000-013000

CLAMP

11

YM124066-59100

CLAMP

12

YM123907-59140

PIPE ASSY

13

YM123907-59540

JOINT BOLT

14

YM119000-59550

PIPE

15

YM123907-59550

PACKING

16

YM123907-59560

HOSE

17

YM22190-080002

SEAL

18

YM23414-080000

GASKET

19

YM23857-030000

JOINT BOLT

20

YM120324-55750

SEPARATOR

21

YM120324-55760

ELEMENT, FUEL OIL

22

YMX0582810173

GASKET

23

YMX0580121073

O-RING

24

YMX0311121522

CENTER BOLT

25

YMX0300120414

GASKET

26

YMX0313080110

BOLT

27

YMX0588080273

BOLT

28

YMX2740134001

COVER

29

YMX2540025002

CASE ASSY

30

YMX0600160122

SPRING

31

YMX0314080110

PLUG

32

YM121750-59910

JOINT

33

YM22190-140002

SEAL

34

YM23857-080000

JOINT BOLT

35

YM129612-52100

FUEL PUMP

36

YM129136-66852

SUPPORT
