Запчасти Komatsu WB91R-2 РАДИАТОР КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА
28
9
33
8
1
3
27
4
34
32
7
8
5
6
25
26
2
15
35
35
20
21
24
23
22
14
16
15
14
12
19
11
18
17
10
29
30
31
11
12
13
1
312607124
COMPLETE RADIATOR
2
875600001
COMPLETE RADIATOR BODY
3
875600002
CONVEYOR
4
875600003
WALL
5
875600004
GASKET
6
875600005
PLUG
7
801014046
BOLT
8
802070006
WASHER
9
875600006
NUT
10
875600007
SPACER
11
875600008
DAMPER RUBBER
12
875600009
WASHER
14
801520066
STUD
15
312607767
GASKET
16
312607766
GASKET
17
312607130
COCK
18
855051111
O-RING
19
802660617
CLAMP
20
312607091
RADIATOR SUPPORT
22
802170001
WASHER
24
802170001
WASHER
25
801880208
SELF-LOCKING NUT
26
500411236
RUBBER
27
312607132
PROTECTION
29
312607784
PIPE
31
801920107
NUT
32
312607796
GASKET
33
312607804
GASKET L=410 MM
34
312607805
GASKET L=485 MM
35
802148010
RUBBER WASHER
