Запчасти Komatsu WB91R-2 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu WB91R-2 - ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ
5
A
49
A
44
A
B
B
25
53
54
45
51
46
46
48
47
38
35
52
36
42
34
31
32
43
38
35
29
36
34
41
28
31
32
43
27
38
29
35
36
40
26
28
34
41
32
31
30
38
35
36
68
41
1
28
34
31
32
68
43
29
24
61
22
59
39
20
19
41
21
57
58
13
23
18
60
16
17
69
67
12
2
9
66
55
11
56
65
63
64
8
67
7
62
4
15
14
3

Артикул

Название

Примечание

Количество

\0

871070039

ASPIRATED ENGINE

1

YM123910-03090

HOSE

2

YM123900-07900

LIFTER

3

YM26106-100202

BOLT

4

YM723900-11100

CYLINDER HEAD, ASSY

5

HEAD ASSY

7

YM123900-11080

GASKET

8

YM123900-11090

GASKET

9

YM119000-11810

PIPE

11

YM23871-005000

PLUG

12

YM27241-400000

PLUG

13

YM27310-090000

COTTER

14

YM123900-11100

VALVE

15

YM123900-11110

VALVE

16

YM123900-11120

SPRING

17

YM121850-11150

GASKET

18

YM121850-11180

RETAINER

19

YM119171-11370

CAP

20

YM119625-11870

PROTECTOR

21

YM119625-11880

GASKET

22

YM119625-11900

RETAINER

23

YM26216-060302

STUD

24

YM26366-060002

NUT

25

YM24311-000320

O-RING

26

YM123900-11200

SUPPORT

27

YM123900-11240

SHAFT

28

YM119000-11280

SPRING

29

YM123900-11510

SUPPORT

30

YM123900-11520

SUPPORT

31

YM123900-11650

ARM ASSY

32

YM129150-11230

SCREW

34

YM129150-11750

NUT

35

YM123900-11660

ARM ASSY

36

YM129150-11230

SCREW

38

YM129150-11750

NUT

39

YM22242-000180

RING

40

YM26577-040162

SCREW

41

YM119593-11300

BOLT

42

YM26106-080702

BOLT

43

YM26366-080002

NUT

44

YM124160-01751

CAP

45

YM123900-11330

BONNET

46

YM119593-03100

FILTER

47

YM123900-03201

PLATE

48

YM123900-03210

GASKET

49

YM123900-03220

JOINT

51

YM123900-11310

GASKET

52

YM26022-050122

SCREW

53

YM124160-11360

KNOB

54

YM24311-000120

O-RING

55

YM23297-350121

RETAINER

56

YM26106-120202

BOLT

57

YM123901-03270

BREATHER, ASSY

58

YM123901-03240

FILTER

59

YM123901-03250

COVER

60

YM123901-03260

BREATHER

61

YM26116-050102

BOLT

62

YM123901-03280

ELBOW

63

YM119773-03300

HOSE

64

YM119773-03250

HOSE

65

YM119773-03270

PROTECTION

66

YM127605-03400

PIPE

67

YM23000-016000

CLAMP

68

YM23000-041000

CLAMP

69

YM23000-041000

CLAMP

Выбрано товаров: 65
