Запчасти Komatsu WB91R-2 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu WB91R-2 - ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ
44
32
1
49
31
25
31
9
39
53
32
54
45
51
46
38
46
35
36
48
42
47
34
52
31
32
43
38
35
36
29
34
41
28
27
43
38
29
35
36
26
40
28
34
41
43
30
38
35
36
41
28
34
31
32
43
29
24
22
39
19
20
41
21
13
23
18
16
17
12
4
11
5
2
8
7
3
15
14

Артикул

Название

Примечание

Количество

\0

871070017

Aspirated engine

1

YM123910-03090

Hose

2

YM123900-07900

Lifter

3

YM26106-100202

Bolt

4

YM723900-11100

Cylinder head, Assy

5

Head Assy

7

YM123900-11080

Seal

8

YM123900-11090

Seal

9

YM119000-11810

Pipe

11

YM23871-005000

Plug

12

YM27241-400000

Plug

13

YM27310-090000

Cotter

14

YM123900-11100

Valve

15

YM123900-11110

Valve

16

YM123900-11120

Spring

17

YM121850-11150

Seal

18

YM121850-11180

Retainer

19

YM119171-11370

Cap

20

YM119625-11870

Protector

21

YM119625-11880

Seal

22

YM119625-11900

Retainer

23

YM26216-060302

Stud

24

YM26366-060002

Nut

25

YM24311-000320

O-Ring

26

YM123900-11200

Support

27

YM123900-11240

Shaft

28

YM119000-11280

Spring

29

YM123900-11510

Support

30

YM123900-11520

Support

31

YM123900-11650

Arm Assy

32

YM129150-11230

Screw

34

YM129150-11750

Nut

35

YM123900-11660

Arm Assy

36

YM129150-11230

Screw

38

YM129150-11750

Nut

39

YM22242-000180

Ring

40

YM26577-040162

Screw

41

YM119593-11300

Bolt

42

YM26106-080702

Bolt

43

YM26366-080002

Nut

44

YM124160-01751

Cap

45

YM123900-11330

Bonnet

46

YM119593-03100

Filter

47

YM123900-03201

Plate

48

YM123900-03210

Packing

49

YM123900-03220

Joint

51

YM123900-11310

Packing

52

YM26022-050122

Screw

53

YM124160-11360

Knob

54

YM24311-000120

O-Ring

Выбрано товаров: 50
