Запчасти Komatsu WB91R-1 WB93R-1 ТРАНСМИССИЯ (/9) СИСТЕМА УПРАВЛЕНИЯ

\0

200120045

TRANSMISSION 4WD, ASSY.

1

MI3183203

BRAKE DISK

2

801015109

BOLT

3

801014068

BOLT

4

MIB071138

PLATE

5

MI3183233

WASHER

6

MI3183303

FLANGE

7

MIB071135

GASKET SEAL

8

MI3183243

COVER

9

801014069

BOLT

10

MIB071144

PIN

11

MI3182793

SHIM, 1.800 mm

11

MI3182803

SHIM, 1.850 mm

11

MI3182813

SHIM, 1.900 mm

11

MI3182823

SHIM, 1.950 mm

11

MI3182833

SHIM, 2.000 mm

11

MI3182843

SHIM, 2.050 mm

11

MI3182853

SHIM, 2.100 mm

11

MI3182863

SHIM, 2.150 mm

11

MI3182873

SHIM, 2.200 mm

11

MI3182883

SHIM, 2.250 mm

11

MI3182893

SHIM, 2.300 mm

11

MI3182903

SHIM, 2.350 mm

12

MI3183173

SPACER

13

MIB071128

BEARING

14

MI3183143

SHAFT

15

MI3183193

GEAR

16

MI3183283

SYNCHRONIZER GEAR

17

MI3202573

SYNCHRONIZER

18

MIB070023

SPACER

19

MIB071134

CAGE, RETAINER

20

MI3183183

GEAR

21

MI3183153

GEAR

22

MI3183163

SPACER
