Запчасти Komatsu WB91R-1 WB93R-1 ПЕРЕДН. ПРИБОРНАЯ ПАНЕЛЬ КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

885170007

FUSE BOX

2

885091006

FUSE 7,5A

2

885091007

FUSE 10A

2

885091008

FUSE 15A

3

885141051

LAMP HOLDER

4

885140026

LAMP

5

885141123

GLASS, NEUTRAL

6

885141126

GLASS, OIOL FILTER CLOGGING

7

885141118

GLASS, AIR FILTER CLOGGING

8

885141129

GLASS, OIL TEMPERATURE

9

885141122

GLASS, ENGINE COOLANT THERMOMETER

10

885141120

GLASS, OIL ENGINE PRESSURE

11

885141117

GLASS, DIRECTION INDICATOR

12

885141119

GLASS, GENERATOR

13

885141111

GLASS, FUEL LEVEL INDICATOR

14

885141116

GLASS, HAND BRAKE

15

885141127

GLASS, 4WD

16

885141114

GLASS, SAIL LIGHT

17

885141115

GLASS, HEADLIGHT

18

801370042

SCREW

19

802070005

WASHER

20

885081086

GLASS, WARNING LIGHT

21

885141098

GLASS, CHECK SAFETY LAMP

22

885081087

LIGHT SWITCH

23

885141100

GLASS, DIRVING LIGHT

24

885081092

SWITCH, EMERGENCY

25

885141101

GLASS, EMERGENCY

26

885411096

CONNECTOR

27

885141072

LAMP

28

885411100

SWITCH HOLDER

29

885411099

PLUG

30

885081089

SWITCH

31

885141102

GLASS, FRONT WORKING LIGHT

32

885081090

SWITCH, WIPER

33

885141104

GLASS, WIPER

34

312205728

FRONT INSTRUMENT BOARD

35

885071015

RELAY

36

885151008

RELAY

37

885071015

RELAY

38

801703005

NUT

39

802070005

WASHER

40

885201094

DIODE HOLDER, ASSY.

41

885081043

BLOCK

42

885241011

PLUG

43

885080055

KEY

44

885081093

COMMUTATOR, ASSY.

45

885091125

COMMUTATOR

46

885081126

DIRECTION INDICATOR
