Запчасти Komatsu WB91R-1 WB93R-1 РУКОЯТЬ И КОВШ МАРКИРОВКА

1

312312081

BUCKET (L=300 mm)

1

312312080

BUCKET (L=400 mm)

1

312312079

BUCKET (L=500 mm)

1

312312078

BUCKET (L=600 mm)

1

312312082

BUCKET (L=700 mm)

1

312312083

BUCKET (L=800 mm)

1

312312084

BUCKET (L=900 mm)

2

801580085

BOLT

3

312204054

TOOTH

4

801703012

NUT

5

312204053

CORNER, L.H.

6

312204052

CORNER, R.H.

7

801014184

BOLT

8

801703012

NUT

9

200323390

PIN

10

802620009

PIN, COTTER

11

500217002

BUSHING

12

500217005

BUSHING

13

860010007

FITTING

14

802030505

RING, NUT

15

802040037

WASHER

16

200321978

PIN

17

200200402

LEVER, R.H.

18

200200403

LEVER, L.H.

19

500217002

BUSHING

20

200703069

TIE-ROD

21

500250056

SPACER

22

500217008

BUSHING

23

312309050

2nd ARM

24

801015584

BOLT

25

500322614

PIN

26

801852212

NUT

27

500270024

SPACER
