Запчасти Komatsu WB91R-1 WB93R-1 КЛАПАН УПРАВЛ-Я ЭКСКАВАТОРОМ (/) РАБОЧЕЕ ОБОРУДОВАНИЕ

\0

844150036

CONTROL VALVE, ASSY. (SERIES TYPE)

\0

844150037

CONTROL VALVE, ASSY. (PARALLEL TYPE)

1

844160126

BLOCK, ASSY.

1

844160125

BLOCK, ASSY.

2

844160129

VALVE, ASSY.

3

844160023

O-RING

4

844160131

PROTECTION, ASSY.

5

844160130

KIT, GASKET

6

844160128

SPOOL RETURN ASSY.

7

844160117

SPRING

8

844160012

SAFETY VALVE

9

844160133

KIT, GASKET

10

844160136

VALVE, SUCTION

10

844160012

SAFETY VALVE

11

844160108

KIT, GASKET

11

844160133

KIT, GASKET

12

844160127

BLOCK, ASSY.

12

844160125

BLOCK, ASSY.

13

844160129

VALVE, ASSY.

14

844160023

O-RING

15

844160131

PROTECTION, ASSY.

16

844160130

KIT, GASKET

17

844160128

SPOOL RETURN UNIT

18

844160117

SPRING

19

844160136

VALVE, SUCTION

19

844160012

SAFETY VALVE

20

844160108

KIT, GASKET

20

844160133

KIT, GASKET

21

844160012

SAFETY VALVE

22

844160133

KIT, GASKET

23

844160138

KIT, GASKET (SERIES CONTROL VALVE)

23

844160139

KIT, GASKET (PARALLEL CONTROL VALVE)
