Запчасти Komatsu WB91R-1 WB93R-1 УПРАВЛ-Е ПОГРУЗ. КОВШОМ КЛАПАН (ДЛЯ КОВША - [4 В 1]) РАБОЧЕЕ ОБОРУДОВАНИЕ

\0

844150100

SHOVEL CONTROL VALVE, ASSY. (FOR BUCKET 4 IN 1)

1

844160084

INLET ELEMENT, ASSY.

2

844160089

MAIN VALVE, ASSY.

3

844160109

KIT, GASKET

4

844160088

SAFETY VALVE, ASSY.

5

844160110

KIT, GASKET

6

844160091

TIE-ROD, ASSY.

7

844160070

BLOCK, BUCKET 4 IN 1, ASSY.

8

844160129

SAFETY VALVE, ASSY.

9

844160023

O-RING

10

844160131

PROTECTION, ASSY.

11

844160130

KIT, GASKET

12

844160128

SPOOL RETURN UNIT

13

844160117

SPRING

14

844160012

SAFETY VALVE, ASSY.

15

844160133

KIT, GASKET

16

844160118

BLOCK, SHOVEL DUMPING, ASSY.

17

844160129

SAFETY VALVE, ASSY.

18

844160023

O-RING

19

844160131

PROTECTION, ASSY.

20

844160130

KIT, GASKET

21

844160128

SPOOL RETURN UNIT

22

844160117

SPRING

23

844160012

SAFETY VALVE, ASSY.

24

844160033

KIT, VALVE GASKET

25

844160116

BLOCK, SHOVEL FLOATING LIFTING, ASSY.

26

844160129

SAFETY VALVE, ASSY.

27

844160023

O-RING

28

844160131

PROTECTION, ASSY.

29

844160130

KIT, GASKET

30

844160147

SPOOL RETURN AND LOCKING UNIT

31

844160117

SPRING

32

844160140

SPRING

33

844160031

BODY

34

844160135

KIT, GASKET
