Запчасти Komatsu WB91R-1 WB93R-1 КАБИНА (7/9) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

312205144

OPERATOR'S CAB, ASSY.

1

816211903

PAD

2

802070005

WASHER

3

801220193

SCREW

4

816211962

RETAINER

5

816211961

GASKET

6

816213212

PLATE

7

802150508

SPRING WASHER

8

802070008

WASHER

9

801014065

BOLT

10

816210474

BASE

11

816210473

TIE-ROD, ASSY.

12

816210475

PIN

13

816211479

SPACER

14

801014122

BOLT

15

816213865

WASHER

16

816211472

GASKET

17

802148010

WASHER

18

801014068

BOLT

19

816213785

MIRROR, L.H., ASSY.

20

816213830

MIRROR

21

816213831

SUPPORT

22

802070008

WASHER

23

801014067

BOLT

24

816211979

WIPER MOTOR, FRONT

25

816211980

WIPER ARM, FRONT

26

816210297

WIPER BLADE, FRONT

27

816210300

ROOF LAMP

28

885140008

LAMP

29

816211981

WIPER MOTOR, REAR

30

816211982

WIPER ARM, REAR

31

816211607

WIPER BLADE, REAR

32

311305075

CANOPY

32

312205784

CANOPY

33

816212790

ROOF, FRONT

34

816212791

ROOF

35

816212792

ROOF, REAR

36

816212010

SPRING

37

816210658

WASHER

38

801350067

SCREW

39

816213784

MIRROR, R.H., ASSY. (OPTIONAL)

40

816213853

ARM (OPTIONAL)

41

816213830

MIRROR (OPTIONAL)

42

802070008

WASHER (OPTIONAL)

43

802120008

SPRING WASHER (OPTIONAL)

44

801014068

BOLT (OPTIONAL)

45

816213803

COVER

46

888010007

FAN (OPTIONAL)

47

801014067

BOLT (OPTIONAL)

48

802120008

SPRING WASHER (OPTIONAL)

49

802070008

WASHER (OPTIONAL)

50

816212549

PLUG
