Запчасти Komatsu WB91R-1 WB93R-1 КРЫШКИ УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

312205660

COVER

2

801014135

BOLT

3

801852212

NUT

4

802160003

WASHER

5

802170003

WASHER

6

818000014

CLIP

7

311305609

FRONT RADIATOR GRILL

8

802070006

WASHER

9

311305054

GRILLE

10

802070008

WASHER

11

801250072

SCREW

12

312205661

SUPPORT

13

801104102

SCREW

14

311305738

PEG

15

801852410

NUT

16

312205148

HOOD

17

802700009

RETAINER

18

801014095

BOLT

19

312201068

SUPPORT, R.H.

20

312201069

SUPPORT, L.H.

21

801852210

NUT

22

801852208

NUT

23

802148010

WASHER

24

312205731

SPACER

25

312205730

SHIM PACK

26

801014070

BOLT

27

855711081

GASKET

28

801852206

NUT

29

801014044

BOLT

30

312205800

PROTECTION

31

816213369

KIT, RETAINER

32

312205146

HOOD

33

312205104

CAP, ASSY.

33

312205153

PLUG

34

802550362

RIVET

34

801370015

SCREW

35

801014095

BOLT

36

802148013

WASHER

37

312205147

HOOD

38

855710058

GASKET

39

312205139

PLUG

40

312205695

UPPER SQUAB

41

312205700

FASTENING PLATE

42

802070010

WASHER
