Запчасти Komatsu WB91R-1 WB93R-1 ЗАДН. МОСТ (/) СИСТЕМА УПРАВЛЕНИЯ

\0

200040597

REAR AXLE, ASSY.

1

MI3142823

AXLE SHAFT, R.H.

2

MI3142833

AXLE SHAFT, L.H.

3

MIB070388

BOLT

4

MI3147893

PLATE

5

MI3147883

BRAKE DISK

6

MI3147803

GEAR, RING

7

MI3147813

SUPPORT

8

MI3147863

SWING CIRCLE

9

MI3147833

DRIVEN GEAR

10

MIB070667

ROLLER BEARING

11

MI3147853

SPACER

12

MI3147823

PIN

13

MI3147873

RING, SNAP

14

MI3147903

SHIM, 4.550 mm

14

MI3147913

SHIM, 4.650 mm

14

MI3147923

SHIM, 4.750 mm

14

MI3147933

SHIM, 4.850 mm

14

MI3147943

SHIM, 4.950 mm

14

MI3147953

SHIM, 5,050 mm

14

MI3147963

SHIM, 5,150 mm

14

MI3147973

SHIM, 5.250 mm

14

MI3147983

SHIM, 5,350 mm

14

MI3147993

SHIM, 5.450 mm

14

MI3148003

SHIM, 5.550 mm

14

MI3148013

SHIM, 5.650 mm

14

MI3148023

SHIM, 5.750 mm

15

MIB070669

BEARING

16

MIB070670

BEARING

17

MI3148043

SPACER

18

MIB070668

GASKET

19

MI3148033

DRIVE AXLE, ASSY.

20

MI3152903

STEERING COLOUMN

21

MI3140983

NUT

22

860010007

FITTING
