Запчасти Komatsu WB91R-1 WB93R-1 ЗАДН. МОСТ (/) СИСТЕМА УПРАВЛЕНИЯ

\0

200040597

REAR AXLE, ASSY.

1

MIB070337

BOLT

2

MI3147603

SUPPORT, L.H.

3

MI3147763

SHIM, 0.500 mm

3

MI3147753

SHIM, 0.200 mm

3

MI3147743

SHIM, 0.150 mm

4

MIB070664

BEARING

5

MI3211863

BEVEL GEAR, ASSY.

6

MI3142543

PLANETARY CARRIER

7

MIB070613

SCREW

8

MI3184443

PIN

9

MI3147693

PIN

10

MI3142853

HUB

11

MIB070665

BEARING

12

MI3147593

SUPPORT, R.H.

13

MI3147683

FITFH WHEEL

14

MI3147633

PLANET WHEEL

15

MI3147613

CROWN WHEEL, R.H.

16

MI3147673

SPACER, GEAR (1.50 mm)

16

MI3147663

SPACER, GEAR (1.60 mm)

16

MI3147653

SPACER, GEAR (1.70 mm)

16

MI3184463

SPACER, GEAR (1.40 mm)

16

MI3184473

SPACER, GEAR (1.80 mm)

17

MI3147623

CROWN WHEEL, L.H.

18

MIB070559

BEARING

19

MI3136663

SHIM, 3.500 mm

19

MI3136673

SHIM, 3.600 mm

19

MI3136683

SHIM, 3.700 mm

19

MI3136693

SHIM, 3.800 mm

19

MI3136703

SHIM, 3.900 mm

19

MI3136713

SHIM, 4.000 mm

19

MI3136723

SHIM, 4.100 mm

19

MI3136733

SHIM, 4.200 mm

19

MI3136743

SHIM, 4.300 mm

19

MI3136753

SHIM, 4.400 mm

19

MI3136763

SHIM, 4.500 mm

20

MIB070663

DOWEL

21

MI3190663

COVER

22

MIB070594

PLUG

23

MIB070337

BOLT

24

MI3137033

SPACER

25

MI3136773

SHIM, 0.500 mm

25

MI3136783

SHIM, 1.000 mm

25

MI3136793

SHIM, 1.025 mm

25

MI3136803

SHIM, 1.050 mm

25

MI3136813

SHIM, 1.075 mm

25

MI3136823

SHIM, 1.100 mm

25

MI3136833

SHIM, 1.125 mm

25

MI3136843

SHIM, 1.150 mm

25

MI3136853

SHIM, 1.175 mm

25

MI3136863

SHIM, 1.200 mm

25

MI3136873

SHIM, 1.225 mm

25

MI3136883

SHIM, 1.250 mm

25

MI3136893

SHIM, 1.275 mm

25

MI3136903

SHIM, 1.300 mm

25

MI3136913

SHIM, 1.325 mm

25

MI3136923

SHIM, 1.350 mm

25

MI3136933

SHIM, 1.375 mm

25

MI3136943

SHIM, 1.400 mm

25

MI3136953

SHIM, 1.425 mm

25

MI3136963

SHIM, 1.450 mm

25

MI3136973

SHIM, 1.475 mm

25

MI3136983

SHIM, 1.500 mm

26

MIB070239

BEARING

27

MIB070319

GASKET

28

MI3211833

FLANGE

29

MI3100323

WASHER

30

MI3143623

NUT
