Запчасти Komatsu WB91R-1 WB93R-1 ПЕРЕДНИЙ МОСТ (WD) (/) СИСТЕМА УПРАВЛЕНИЯ

\0

200040598

FRONT AXLE 4WD, ASSY.

1

MI3165303

RING, NUT

2

MIB070213

BEARING

3

MIB070434

BOLT

4

MI3165313

PLATE

5

MIB070950

SCREW

6

MI3202673

SUPPORT

7

MI3225303

PLANETARY CARRIER

8

MI3145143

SWING CIRCLE

9

MI3226303

GEAR, ASSY.

10

MI3145133

SPACER

11

MI3225313

PIN

12

MIB071634

PEG

13

MI3227013

BEVEL GEAR, ASSY.

14

MIB070792

BOLT

15

MIB070753

BEARING

16

MI3145223

SHIM, 3.400 mm

16

MI3145233

SHIM, 3.500 mm

16

MI3145243

SHIM, 3.600 mm

16

MI3145253

SHIM, 3.700 mm

16

MI3145263

SHIM, 3.800 mm

16

MI3145273

SHIM, 3.900 mm

16

MI3145283

SHIM, 4.000 mm

16

MI3145293

SHIM, 4.100 mm

16

MI3145303

SHIM, 4.200 mm

16

MI3145313

SHIM, 4.300 mm

16

MI3145323

SHIM, 4.400 mm

17

MI3145193

SPACER

18

MI3145333

SHIM, 0.500 mm

18

MI3145343

SHIM, 1.000 mm

18

MI3145353

SHIM, 1.025 mm

18

MI3145363

SHIM, 1.050 mm

18

MI3145373

SHIM, 1.075 mm

18

MI3145383

SHIM, 1.100 mm

18

MI3145393

SHIM, 1.125 mm

18

MI3145403

SHIM, 1.150 mm

18

MI3145413

SHIM, 1.175 mm

18

MI3145423

SHIM, 1.200 mm

18

MI3145433

SHIM, 1.225 mm

18

MI3145443

SHIM, 1.250 mm

18

MI3145453

SHIM, 1.275 mm

18

MI3145463

SHIM, 1.300 mm

18

MI3145473

SHIM, 1.325 mm

18

MI3145483

SHIM, 1.350 mm

18

MI3145493

SHIM, 1.375 mm

18

MI3145503

SHIM, 1.400 mm

18

MI3145513

SHIM, 1.425 mm

18

MI3145523

SHIM, 1.450 mm

18

MI3145533

SHIM, 1.475 mm

18

MI3145543

SHIM, 1.500 mm

19

MIB070294

BOLT

20

MIB070331

BEARING

21

MIB070256

GASKET

22

MI3172983

FLANGE, ASSY.

23

MI3154203

NUT
