Запчасти Komatsu WB70A-1 КЛАПАН УПРАВЛ-Я ЭКСКАВАТОРОМ (ДЛЯ МОЛОТА) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

844010251

CONTROL VALVE, ASSY.

1

844100428

ELEMENT, ASSY

2

844100381

KIT, FLANGE

3

801104077

SCREW

4

855350024

GASKET

5

855021116

O-RING

6

844100413

VALVE, ASSY.

7

855021017

O-RING

8

855090014

RING, WEAR

9

855051015

O-RING

10

844100382

VALVE

11

844100376

GASKET

12

844100431

SPOOL RETURN UNIT

13

844100396

SPRING

14

844100425

ELEMENT, ASSY

15

844100381

KIT, FLANGE

16

801104077

SCREW

17

855350024

GASKET

18

855021116

O-RING

19

844100427

CAP, ASSY.

20

855021017

O-RING

21

855080015

RING, WEAR

22

855051015

O-RING

23

844100382

VALVE

24

844100376

GASKET

25

844100431

SPOOL RETURN UNIT

26

844100396

SPRING

27

844100426

VALVE, ASSY.

28

855021017

O-RING

29

855090014

RING, WEAR

30

855051015

O-RING

31

844100422

KIT, TIE-ROD

32

844100424

KIT, GASKET
