Запчасти Komatsu WB70A-1 КЛАПАН УПРАВЛ-Я ЭКСКАВАТОРОМ (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

844010243

CONTROL VALVE, ASSY.

1

844100412

ELEMENT, ASSY

2

844100381

KIT, FLANGE

3

801104077

SCREW

4

855350024

GASKET

5

855021116

O-RING

6

844100401

VALVE, ASSY.

7

855021017

O-RING

8

855090014

RING, WEAR

9

855051015

O-RING

10

844100382

VALVE

11

844100376

GASKET

12

844100413

VALVE, ASSY.

13

855021017

O-RING

14

855090014

RING, WEAR

15

855051015

O-RING

16

844100431

SPOOL RETURN UNIT

17

844100396

SPRING

18

844100418

ELEMENT, ASSY

19

844100381

KIT, FLANGE

20

801104077

SCREW

21

855350024

GASKET

22

855021116

O-RING

23

844100413

VALVE, ASSY.

24

855021017

O-RING

25

855090014

RING, WEAR

26

855051015

O-RING

27

844100382

VALVE

28

844100376

GASKET

29

844100419

VALVE, ASSY.

30

855021017

O-RING

31

855090014

RING, WEAR

32

855051015

O-RING

33

844100431

SPOOL RETURN UNIT

34

844100396

SPRING
