Запчасти Komatsu WB70A-1 УПРАВЛ-Е ПОГРУЗ. КОВШОМ КЛАПАН (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

844010232

CONTROL VALVE, ASSY.

1

844100391

INLET ELEMENT, ASSY.

2

844100392

MAIN VALVE, ASSY.

3

855021814

O-RING

4

844100388

CAP, ASSY.

5

855150063

GASKET

6

844100375

CAP, ASSY.

7

855021119

O-RING

8

844100372

WASHER

9

844100369

TIE-ROD, ASSY.

10

844100403

ELEMENT, ASSY

11

844100381

KIT, FLANGE

12

855350024

GASKET

13

855021116

O-RING

14

801104077

SCREW

15

844100405

VALVE, ASSY.

16

855021017

O-RING

17

855090014

RING, WEAR

18

855051015

O-RING

19

844100404

KIT, PLUG

20

855150054

GASKET

21

844100382

VALVE

22

844100376

GASKET

23

844100399

SPOOL RETURN UNIT

24

844100400

SPRING

25

844100406

CASE, ASSY.

26

844100407

PLUG

27

844100388

CAP, ASSY.

28

855150063

GASKET

29

844100390

KIT, GASKET
