Запчасти Komatsu WB70A-1 КАБИНА (/7) ЧАСТИ КОРПУСА И КАБИНА

Схема запчастей Komatsu WB70A-1 - КАБИНА (/7) ЧАСТИ КОРПУСА И КАБИНА
34
28
35
a
37
a
b
b
24
c
c
39
d
33
d
30
20
36
32
19
38
40
23
25
26
18
21
41
22
42
29
27
47
31
50
51
48
49
43
48
44
45
46
12
13
5
2
7
10
8
11
9
6
15
16
4
17
14
1
3

Артикул

Название

Примечание

Количество

\0

366505085

OPERATOR'S CAB, ASSY.

1

816214489

OPERATOR'S SEAT STAND

2

816214490

WINDOW

3

801250058

SCREW

4

801852206

NUT

5

816214487

KNOB

6

816214346

LOCK, BLOCK

7

801200018

SCREW

8

802070008

WASHER

9

801703208

NUT

10

816214488

HANDLE

11

801200696

SCREW

12

801014067

SCREW

13

802070008

WASHER

14

816214491

STRIKER

15

801014093

SCREW

16

802070010

WASHER

17

801703209

NUT

18

816214492

STRIKER

19

802070010

WASHER

20

801014094

BOLT

21

802070010

WASHER

22

801014094

BOLT

23

816214486

SPRING

24

802150008

SPRING WASHER

25

802150008

SPRING WASHER

26

801852208

NUT

27

801852208

NUT

28

802150008

SPRING WASHER

29

802150008

SPRING WASHER

30

816214493

GASKET

31

888011031

DIFFUSER

32

816214494

DIFFUSER

33

885411419

LAMP HOLDER

34

885141195

GLASS

35

885141197

GLASS

36

885081136

SWITCH

37

885141196

GLASS

38

885081086

GLASS, WARNING LIGHT

39

885141099

GLASS, HEATER

40

885081094

SWITCH, FAN

41

885411097

SUPPORT

42

885411098

SUPPORT

43

816215091

COVER, LOWER, REAR, R.H.

44

366505709

COVER, LOWER, REAR, L.H.

45

366505711

COVER, FRONT, R.H.

46

366505712

COVER, FRONT, L.H.

47

816215092

PANEL, UNDER-ROOF

48

366505495

SCREW

49

816214508

WASHER

50

816214506

WASHER

51

816215093

COVER, LATERAL

Выбрано товаров: 52
