Запчасти Komatsu WB70A-1 КАБИНА (/7) ЧАСТИ КОРПУСА И КАБИНА

\0

366505085

OPERATOR'S CAB, ASSY.

1

816210643

LOCK, R.H., ASSY.

2

816210642

LOCK, L.H., ASSY.

3

801200697

SCREW

4

816214446

COVER, R.H.

5

816214447

COVER, L.H.

6

801350065

SCREW

7

816214508

WASHER

8

816213314

PIN

9

816213313

STRIKER

10

802070012

WASHER

11

816214509

NUT

12

816214448

TIE-ROD, R.H.

13

816214449

TIE-ROD, L.H.

14

802510111

PEG

15

802070010

WASHER

16

816214450

BASE

17

801250060

SCREW

18

802070008

WASHER

19

885411035

RUBBER

20

816212396

BOOT

21

801350065

SCREW

22

816214506

WASHER

23

816214451

WORK LIGHT

24

801940123

PLUG

25

801014091

BOLT

26

802070010

WASHER

27

802070010

WASHER

28

801852210

NUT

29

816215087

ARM, R.H.

30

816215088

ARM, L.H.

31

816214452

MIRROR, DRIVING

32

801014067

BOLT

33

802070008

WASHER

34

802070453

RUBBER

35

802070454

SPACER

36

802070455

SUPPORT

37

801014091

BOLT

38

802070010

WASHER

39

816214456

SUPPORT

40

816210258

COAT HOOK

41

801350065

SCREW
