Запчасти Komatsu WB70A-1 ГОЛОВКА ЦИЛИНДРОВ И КРЫШКА ГОЛОВКА ЦИЛИНДРОВ

\0

871070067

ENGINE, ASSY.

1

YM129900-07900

LIFTER, ENGINE

2

YM26106-080162

BOLT

3

YM123907-11550

CAP VALVE

4

YM129907-11700

HEAD ASSY, CYLINDER

9

YM129907-11800

GUIDE VALVE

10

YM123907-11820

STUD

11

YM23876-020000

PLUG

12

YM23876-030000

PLUG

13

YM27241-400000

PLUG

14

YM129907-11110

VALVE, EXHAUST

15

YM129907-11120

SPRING, VALVE

16

YM119620-11180

RETAINER, SPRING

17

YM124160-11340

SEAL, VALVE STEM

18

YM124950-11340

SEAL, VALVE EXHAUST

19

YM129907-11510

BRACKET

21

YM129150-11750

NUT

22

YM123907-11830

SCREW

23

YM27310-070001

COTTER

25

YM129907-11100

VALVE, SUCTION

26

YM119625-11880

SEAT, NOZZLE

27

YM24311-000120

O-RING

28

YM119593-11301

BOLT

29

YM129907-11341

SUPPORT ASSY

30

YM129907-11250

SHAFT

31

YM129907-11260

SUPPORT

32

YM129907-11270

SUPPORT

33

YM123907-11280

WASHER

34

YM129907-11650

ROCKER SHAFT

36

YM129150-11230

SCREW

37

YM129150-11750

NUT

38

YM129907-11660

ROCKER SHAFT

40

YM129150-11230

SCREW

41

YM129150-11750

NUT

42

YM129907-11920

RETAINER

43

YM26226-080222

STUD

44

YM26106-080402

BOLT

45

YM26106-080602

BOLT

46

YM26106-080602

BOLT

47

YM119802-11870

PROTECTION, NOZZLE

48

YM129907-11950

BOLT

49

YM26306-080002

NUT

50

YM124160-01751

PLUG

51

YM129907-11320

COVER

52

YM129907-03010

PLATE

53

YM129907-03060

DIAPHRAGM

54

YM129907-03070

DIAPHRAGM

55

YM123907-03100

DIAPHRAGM

56

YM123907-03110

PLATE

57

YM123907-03120

PLATE

58

YM123907-03140

SPRING

61

YM129907-11310

GASKET

62

YM119640-61400

PLUG

63

YM22857-500100

SCREW

64

YM22857-500100

SCREW

65

YM124160-11360

PLUG

66

YM24311-000120

O-RING

67

YM24311-000320

O-RING

68

YM129907-11910

RETAINER

76

YM977770-01212

GASKET, LIQUID
