Запчасти Komatsu WB70A-1 СТАРТЕР ГОЛОВКА ЦИЛИНДРОВ

Схема запчастей Komatsu WB70A-1 - СТАРТЕР ГОЛОВКА ЦИЛИНДРОВ
A
26
1
23
21
24
25
19
20
5
13
6
15
13
12
22
11
14
10
7
9
8
2

Артикул

Название

Примечание

Количество

1

871070067

ENGINE, ASSY.

2

YM123900-77400

ROTOR,ASSY.

5

YM123900-77440

COIL ASSY.,FIELD

6

YM123900-77450

BRUSH (+)

7

YM123900-77460

COVER, REAR

8

YM123900-77480

BRUSH HOLDER, ASSY.

9

YM123900-77450

BRUSH (+)

10

YM121254-77590

SPRING

11

YM123900-77510

PINION, ASSY.

12

YM123900-77520

CLUTCH, ASSY.

13

YMX2240610100

BEARING

14

YM123900-77540

SHAFT

15

YM119131-77550

KIT, STOPPER

19

YM129900-77591

SWITCH, MAGNETIC

20

YM123900-77610

RETAINER

21

YM129900-77620

SHIFT LEVER SET

22

YM123900-77640

BOLT

23

YM123900-77650

PAN ASSY., DUST

24

YM123900-77710

HOUSING

25

YM171008-77750

COVER

26

YM26116-120302

BOLT

Выбрано товаров: 21
