Запчасти Komatsu WB70A-1 СИСТЕМА ОХЛАЖДЕНИЯ ГОЛОВКА ЦИЛИНДРОВ

\0

871070067

ENGINE, ASSY.

1

YM129907-42000

PUMP, ASSY.

11

YM129900-42020

GASKET

12

YM26106-060302

BOLT PLATED

13

YM26106-080552

BOLT

14

YM129900-42461

PULLEY

15

YM25132-004250

V-BELT

16

YM129980-44741

FAN, COOLING

17

YM26014-080142

BOLT

18

YM129940-49800

THERMOSTAT, ASSY.

19

YM129980-49530

COVER

20

YM121850-49540

GASKET

21

YM121850-49550

GASKET

22

YM129907-49730

SUPPORT

23

YM121850-49810

THERMOSTAT

25

YM105582-59150

BOLT, PIPE JOINT

26

YM23387-040800

JOINT

27

YM23414-080000

GASKET

28

YM23875-030000

PLUG

29

YM26106-060122

SCREW

30

YM26106-060202

BOLT

31

YM26106-060552

BOLT

32

YM129900-49870

GASKET

33

YM23414-080000

GASKET

34

YM26106-080122

BOLT

35

YM26106-080602

BOLT

36

YM121450-42450

PLUG

37

YM121250-44901

WATER TEMPERATURE TRANSMITTER (ALARM)

38

YM124465-44950

GASKET

39

YM124465-44950

GASKET

40

YM129907-49610

PIPE, ASSY.

41

YM129907-49710

PIPE

42

YM129907-49750

PROTECTION

43

YM124722-59050

CLAMP

44

YM129907-49620

PIPE, ASSY.

45

YM129907-49720

PIPE

46

YM124722-59050

CLAMP

47

YM119620-49290

COCK
