Запчасти Komatsu WB70A-1 КАБИНА (/7) ЧАСТИ КОРПУСА И КАБИНА

\0

306505065

OPERATOR'S CAB, ASSY.

1

801250161

BOLT

2

816214506

WASHER

3

816215089

BUSHING

4

816214468

GASKET

5

816214469

LATCH ASSY., R.H.

6

816214470

LATCH ASSY., L.H.

7

802070006

WASHER

8

801852206

NUT

9

801852471

CAP

10

801852472

SUPPORT

11

801852472

SUPPORT

12

802148009

WASHER

13

801703208

NUT

14

801014069

BOLT

15

802070008

WASHER

16

802148009

WASHER

17

802148474

BUSHING

18

802148475

ROD

19

802148009

WASHER

20

801703208

NUT

21

801014069

BOLT

22

802148009

WASHER

23

802148474

BUSHING

24

802148009

WASHER

25

802070008

WASHER

26

801703208

NUT

27

801703477

SPRING

28

801104104

SCREW

29

801104478

WHEEL

30

802070008

WASHER

31

801703208

NUT

32

802070008

WASHER

33

802070008

WASHER

34

801703208

NUT

35

802150008

SPRING WASHER

36

801852208

NUT

37

885270488

CAB WIRING

38

816214480

LOCKPLATE

39

885411049

RUBBER

40

816215090

FRAME, REAR WINDOW

41

816024528

GLASS, REAR

42

816214484

GASKET, UPPER

43

816214485

SEAL, REAR

44

816214483

SEAL, REAR

45

816214481

GASKET, LATERAL, REAR

46

816214479

PLUG

47

816214476

SPACER

48

801250060

SCREW

49

801852206

NUT

50

801852473

RETAINER

51

801350091

SCREW
