Запчасти Komatsu WB70A-1 КАБИНА (/7) ЧАСТИ КОРПУСА И КАБИНА

\0

306505065

OPERATOR'S CAB, ASSY.

1

816214419

SUPPORT

2

801014067

BOLT

3

802148009

WASHER

4

816214420

LEVER, ASSY.

5

816214421

WIPER MOTOR, FRONT

6

801250059

BOLT

7

802120006

SPRING WASHER

8

801703208

NUT

9

802150508

SPRING WASHER

10

816214422

SPACER

11

812214423

NUT

12

816214424

COVER

13

816214425

ARM

14

816214426

FLEX HORN

15

801250044

SCREW

16

802120008

SPRING WASHER

17

801703208

NUT

18

816214427

SNAP PIN

19

801014069

BOLT

20

816214428

GASKET

21

816214429

SPACER

22

802070008

WASHER

23

801852208

NUT

24

816214430

CAP

25

311305085

HANDLE, EXTERN, R.H.

26

311305086

HANDLE, EXTERNAL

27

816213375

PUSHBUTTON, ASSY.

28

816214431

GASKET

29

801250057

BOLT

30

802148006

WASHER

31

816214432

RUBBER

32

801250060

SCREW

33

802070006

WASHER

34

802120006

SPRING WASHER

35

802148006

WASHER

36

816214433

BRACKET

37

816214510

NUT

38

816214511

NUT

39

816214434

BOOT

40

801250045

SCREW

41

802070005

WASHER

42

816214435

RUBBER

43

816214436

PIN, PISTON

44

802510111

PEG

45

816214437

FITTING

46

816214438

LINK

47

816214439

HANDLE

48

801014046

BOLT

49

802070006

WASHER

50

801703206

NUT

51

802070008

WASHER

52

801852208

NUT

53

816214440

CLAMP

54

801250059

BOLT

55

816214441

TANK

56

816214442

PIPE 800 mm

57

816214443

UNION

58

816214444

PIPE 1400 mm

59

816214445

PIPE 3600 mm

60

816214551

VALVE
