Запчасти Komatsu WB70A-1 ЗАДН. РАМА РАМА

1

366501066

FRAME, REAR

2

366506600

PLATE

3

801014266

BOLT

4

801852220

NUT

5

366505718

PROTECTION, L.H.

6

366505059

L.H. CASE

7

801015110

BOLT

8

802150510

SPRING WASHER

9

366505061

L.H. MUDGUARD

10

801015105

BOLT

11

366505058

R.H. CASE

12

366505060

R.H. MUDGUARD

13

366505693

PROTECTION, R.H.

14

801015068

BOLT

15

802170000

WASHER

16

816211680

PLATE

17

801880206

NUT

18

816211495

CYLINDER

19

802170001

WASHER

20

802610055

PIN, COTTER

21

855711073

GASKET

22

366515600

R.H. CLOSURE

23

801015108

BOLT

24

802150510

SPRING WASHER

25

366515601

COVER, L.H.

26

366536600

SUPPORT

27

801015109

BOLT

28

801880001

NUT

29

802170002

SPRING WASHER

30

801200797

SCREW

31

366501780

PLATE

32

801880216

NUT

33

366505738

GASKET

34

885710058

GASKET

35

802660501

COLLAR
