Запчасти Komatsu WB70A-1 ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ

\0

871070014

ENGINE, ASSY.

1

YM119006-03090

PIPE

2

YM129150-03100

RETAINER

3

YM26106-080122

BOLT

4

YM129900-07900

LIFTER

5

YM729900-11100

HEAD,ASSY.

8

YM129150-11810

GUIDE VALVE

10

YM23871-005000

PLUG

11

YM27241-400000

PLUG

12

YM129900-11100

VALVE, INLET

13

YM129900-11110

VALVE EXHAUST

14

YM129900-11120

SPRING, VALVE

15

YM129795-11180

RETAINER, SPRING

16

YM121400-11340

SEAL, VALVE EXHAUST

17

YM124460-11340

SEAL, VALVE STEM

18

YM129150-11370

CAP VALVE

19

YM119625-11870

PROTECTION, NOZZLE

20

YM119625-11880

SEAT, NOZZLE

21

YM119625-11900

RETAINER

22

YM26216-060202

STUD

23

YM26366-060002

NUT

24

YM27310-080000

COTTER

25

YM129900-11200

ROCKER SHAFT, ASSY.

26

YM129900-11240

ROCKER SHAFT

29

YM129900-11280

SPRING

30

YM129900-11510

SUPPORT

31

YM129900-11520

SUPPORT

32

YM129900-11650

ROCKER SHAFT, SUCTION

33

YM129150-11230

SCREW

35

YM129150-11750

NUT

36

YM129900-11660

ROCKER SHAFT, EXHAUST

37

YM129150-11230

SCREW

39

YM129150-11750

NUT

40

YM22242-000180

RING, SNAP

41

YM26577-040122

SCREW

42

YM129900-11530

STUD

43

YM26366-100002

NUT

44

YM124160-11360

PLUG

45

YM129900-11350

BONNEY ASSY.,HEAD

46

YM129900-11310

GASKET

48

YM129900-11600

PLATE

49

YM26022-050122

SCREW

50

YM119100-11330

UNION

51

YM24311-000120

O-RING

52

YM26106-080162

BOLT

53

YM26106-100652

BOLT

55

YM24311-000320

O-RING

56

YM124160-01751

PLUG
