Запчасти Komatsu WB70A-1 ГЕНЕРАТОР ГОЛОВКА ЦИЛИНДРОВ

Схема запчастей Komatsu WB70A-1 - ГЕНЕРАТОР ГОЛОВКА ЦИЛИНДРОВ
4
5
A
3
5
3
1
6
2
11
10
18
19
12
15
13
17
25
16
14
20
23
3
22
21
8
9
24
26
7

Артикул

Название

Примечание

Количество

\0

871070014

ENGINE, ASSY.

1

YM129470-77340

SPACER

2

YM26116-101202

BOLT

3

YM26366-100002

NUT

4

YM129900-77330

ADJUSTER, BELT

5

YM26014-080252

BOLT

6

YM129900-77210

GENERATOR

7

YM129900-77300

ROTOR,ASSY.

8

YM119129-77320

BEARING

9

YM129900-77310

COIL ASSY.,FIELD

10

YM129900-77320

COVER, ASSY.

11

YM119129-77341

COVER, REAR

12

YM129900-77350

BRUSH ASSY., REGULATOR

13

YM129900-77360

BRUSH, ASSY.

14

YM129900-77370

FLEX HORN

15

YM124080-77390

REGULATOR, ASSY.

16

YM124080-77520

BOLT

17

YM129900-77410

DIODE, ASSY.

18

YM119129-77250

CABLE

19

YM119129-77260

COLLAR

20

YM119129-77840

COVER ASSY., FRONT

21

YM119129-77850

BEARING

22

YM119129-77870

RETAINER

23

YM119129-77930

KIT, SCREW

24

YM129535-77880

PULLEY

25

YM119129-77890

BOLT

26

YM119129-77900

NUT

Выбрано товаров: 27
