Запчасти Komatsu WB156PS-5 A-AA7 ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ

Схема запчастей Komatsu WB156PS-5 - A-AA7 ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ
2
19
18
12
10
14
23
34
29
15
31
20
24
4
22
17
32
28
13
21
37
3
8
25
16
35
36
5
33
1
34
11
30
7
40
38
39
6
9
2
41
27
26

Артикул

Название

Примечание

Количество

|$1

NSS

TURBOCHARGER

1

NSS

DATAPLATE

2

6736-81-8370

BEARING, TURBOCHARGER

3

6731-82-8210

NUT, LOCK

4

NSS

WASHER, PLAIN

5

6736-81-8480

SCREW, DRIVE

6

6733-81-8430

SHIELD, TURBOCHARGER HEAT

7

6732-81-8630

SHAFT AND WHEEL

8

6733-81-8360

RING, RETAINING

9

6736-81-8360

RING, RETAINING

10

6733-81-8330

BAFFLE, OIL

11

NSS

COUPLING, ELBOW HOSE

12

6733-81-8370

RING, RETAINING

13

NSS

NUT, LOCK

14

NSS

END, ADJUSTING

15

6733-81-8460

SEAL, O-RING

16

6733-81-8380

SCREW, HEXAGON HEAD SET

17

6733-81-8270

PLATE, OIL SEAL

18

6733-81-8260

SLINGER, OIL

19

NSS

ACTUATOR, TURBOCHARGER

20

6733-81-6850

SPACER, MOUNTING

21

6735-81-6810

SPACER, MOUNTING

22

6733-81-8350

BEARING, TURBOCHARGER THRUST

23

6733-81-8290

COLLAR, THRUST

24

6742-01-5569

SCREW, HEXAGON HEAD SET

25

NSS

IMPELLER, TURBOCHARGER COMPRESSOR

26

6733-81-8480

PIN, ROLL

27

NSS

HOUSING, TURBOCHARGER BEARING

28

6736-81-8320

SEAL, SPLIT RING

29

6735-81-8370

SCREW, HEXAGON HEAD SET

30

NSS

HOUSING, TURBINE

31

6733-81-8470

RING, RETAINING

32

6735-81-8490

BRACKET, ACTUATOR

33

6733-51-8110

GASKET, ADAPTER

34

6742-01-5564

CLAMP, HOSE

35

6733-81-8320

CONNECTION, ADAPTER

36

6742-01-5566

HOSE, PLAIN

37

NSS

HOUSING, COMPRESSOR

38

6736-81-8440

SEAL, SPLIT RING

39

6743-82-8610

NUT, HEXAGON FLANGE

40

6732-81-8640

BOLT, T

41

6732-81-8390

CLAMP, V-BAND

Выбрано товаров: 42
