Запчасти Komatsu WB156PS-5 A-AA СТАРТЕР ДВИГАТЕЛЬ

Схема запчастей Komatsu WB156PS-5 - A-AA СТАРТЕР ДВИГАТЕЛЬ
32
24
31
22
23
1
38
6
21
4
3
5
42
2
16
17
19
18
15
37
28
30
29
27
34
35
26
36
12
14
11
7
20
25
10
8
9
40
41
39
33
43
36
13
35

Артикул

Название

Примечание

Количество

|$0

6731-82-6520

MOTOR, STARTING

1

ND0281003810

YOKE ASSEMBLY, STARTER

2

ND0280620130

COVER

3

ND0280993560

STARTER KIT (BRUSH) (+)

4

ND0282006220

ARMATURE ASSEMBLY, STARTER

5

ND9491001930

BEARING, BALL (OD35)

6

ND9491001750

BEARING, BALL (OD30)

|$7

ND0283006551

CLUTCH SUBASSEMBLY, STARTER

7

ND0280993270

STARTER KIT (PINION KIT)

8

ND0283006751

CLUTCH SUBASSEMBLY, STARTER (CLUTCH KIT)

9

ND9491004501

BEARING, BALL (FRONT)

10

ND9491001920

BEARING, BALL (REAR)

11

ND9491704040

SPRING, COMPRESSION COIL

12

ND0283810071

SHAFT

13

ND4284012870

HOUSING, STARTER

14

ND1534008600

SWITCH ASSEMBLY, MAGNETIC

15

ND1280995830

STARTER KIT (TERMINAL KIT M)

16

ND0280993160

STARTER KIT (TERMINAL KIT C)

17

ND0536600443

PLUNGER SUBASSEMBLY

18

ND0534040240

GASKET, SWITCH, A

19

ND0535050290

COVER, SOLENOID

20

ND0280650250

BUSHING, DRAIN

21

ND9490474440

BOLT, WITH WASHER (M5, L14)

22

ND0285100500

HOLDER ASSEMBLY, STARTER BRUSH

23

ND9491730571

SPRING, BRUSH SPIRAL

24

ND0285018091

FRAME, STARTER END

25

ND1289610010

BALL, STARTER

26

ND9491704070

SPRING, COMPRESSION COIL

27

ND0283711500

PINION, STARTER

28

ND0283060070

ROLLER, CLUTCH

29

ND0280630030

RETAINER

30

ND0283270171

RETAINER, SNAP

31

ND1289500520

BOLT, STARTER (M6, L182)

32

ND9490076530

SCREW, W/WASHER (M5, L9.4)

33

ND9490064720

SCREW (M6, L50)

34

ND9490076850

SCREW, WITH WASHER (M5, L8)

35

ND9017010061

NUT, HEXAGON (M10)

36

ND9025810001

WASHER, SPRING (M10)

37

ND9490200600

WASHER, FELT (T3)

38

ND0280625790

COVER

39

ND9020006241

WASHER, PLATE (T1)

40

ND9080110050

O-RING (ID 4.8)

41

ND0289015190

SEAL, STARTER

42

ND9490564480

NUT (M10)

43

ND1289500550

BOLT, STARTER

N/I

09842-A0481

DECAL, DO NOT JUMP START

Выбрано товаров: 46
