Запчасти Komatsu WB156PS-5 H97-A HAND МОЛОТ ТРУБЫ ГИДРАВЛИКА

Схема запчастей Komatsu WB156PS-5 - H97-A HAND МОЛОТ ТРУБЫ ГИДРАВЛИКА
33
32
14
31
5
13
4
15
3
2
7
8
1
7
9
23
17
10
16
18
19
11
22
12
11
29
21
30
28
29
27
5
30
19
20
6
26
27
25
23
24

Артикул

Название

Примечание

Количество

2

01010-80865

BOLT

3

01643-10823

WASHER

4

21D-09-51160

CONNECTOR

N/I

2938-62-2140

WASHER

N/I

2938-62-2150

O-RING

5

42N-62-17680

HOSE

6

21D-09-51600

ELBOW

N/I

2938-62-2140

WASHER

N/I

2938-62-2150

O-RING

7

22L-62-24660

SEAL

8

21D-09-61270

ELBOW

9

42N-64-11350

VALVE, CHECK

10

37D-09-66103

CONNECTOR

11

42N-62-17690

HOSE

12

37D-09-7R871

TEE

13

226-09-12650

CONNECTOR

14

42N-62-17190

TUBE

15

226-09-12260

TEE

16

37D-09-8Y004

UNION

17

21D-09-86260

SEAL, BONDED

18

37D-09-6Z505

ELBOW

19

42N-62-17570

HOSE

20

37D-09-6K321

CONNECTOR

20

42N-879-1970

CONNECTOR

N/I

02896-11009

O-RING

N/I

02896-11018

O-RING

21

02789-10315

PLUG, FEMALE

21

02789-10628

PLUG, FEMALE

22

226-09-12280

TEE

23

42N-62-17580

HOSE

24

226-09-12110

ELBOW

N/I

02896-11018

O-RING

25

226-09-12490

CONNECTOR

N/I

02896-11018

O-RING

26

02789-10628

PLUG, FEMALE

27

42N-46-11320

INSERT

28

42N-43-13710

PLATE

29

01016-51040

BOLT

30

01643-11032

WASHER

31

42N-43-14340

SUPPORT, MOUNT SOLENOID VALVE

32

01016-50830

BOLT

33

01643-10823

WASHER

N/I

37D-09-6X461

ELBOW

Выбрано товаров: 43
