Запчасти Komatsu WB156-5 BACKHOE LOADER K-A УПРАВЛ-Е ПОДАЧ. ТОПЛИВАS OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

2

37A-09-61019

PIN

3

42N-43-11440

CABLE, THROTTLE

4

42N-54-14470

PIVOT

5

395-56-11H50

ROLLER BEARING

6

395-56-11H60

BUSHING

7

42N-54-14480

LEVER, PEDAL

8

01252-70845

BOLT, STOP

9

01598-00809

NUT

10

42N-54-15620

PEDAL, THROTTLE

11

01643-31445

WASHER

12

04064-01410

SNAP, RING

13

37B-09-2C006

SPRING, RETURN

14

42N-54-14490

SHAFT, CROSSOVER

15

42N-54-14510

BLOCK, PIVOT

16

42N-54-15960

SCREW

17

42N-54-14520

ROLLER BEARING

|$17

42N-54-14500

TIE ROD

18

42N-54-14530

ROD, TIE

19

37A-09-5Z019

CLEVIS

20

01580-10605

NUT

21

37A-09-61019

PIN

22

42N-54-14560

BUSHING

23

01580-10605

NUT

24

42N-54-14570

PIN

25

01643-31032

WASHER

26

42N-54-17270

NUT

27

42N-54-14580

STOPPER, PEDAL

28

01580-10806

NUT

29

21D-09-15170

BOLT, STOP

30

21D-09-21720

NUT

31

01643-31445

WASHER

32

01643-30823

WASHER

33

01598-00809

NUT

34

42N-43-12930

ROD

35

04250-80847

CLEVIS

36

01580-10806

NUT

37

42N-43-12960

BRACKET

38

01643-30623

WASHER

39

01010-80620

BOLT

40

21D-09-24160

NUT

41

37A-09-61017

PIN, CONTAINED

42

21D-09-24180

NUT

43

2938-54-4230

SCREW

44

37A-09-5Z017

CLEVIS

45

42N-54-17110

BOLT
