A-AA БЛОК ЦИЛИНДРОВ

Запчасти Komatsu WB156-5 BACKHOE LOADER A-AA БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu WB156-5 BACKHOE LOADER - A-AA БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ
3
3
16
15
12
1
11
17
2
7
3
19
18
9
1
14
10
5
8
20
6
4
13
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

6731-22-1110

BLOCK KIT, CYLINDER

|$1

NSS

BLOCK, CYLINDER

1

6732-21-1810

PLUG, EXPANSION

2

6736-21-1820

PLUG, EXPANSION

3

6731-22-7140

PLUG, EXPANSION

4

6732-21-1611

BOLT

|$6

6754-21-1220

CAP ASSEMBLY, MAIN BEARING

5

6732-21-1910

DOWEL, RING

6

NSS

CAP, MAIN BEARING

7

NSS

BLOCK, CYLINDER

8

6732-21-1411

BUSHING

|$11

6731-21-1220

HARDWARE KIT, CYLINDER BLOCK

N/I

6732-21-1910

DOWEL, RING

9

6732-21-6120

DOWEL, PIN

10

6731-21-1190

NOZZLE, PISTON COOLING

11

6732-21-6130

PLUG, EXPANSION

12

6732-21-6140

DOWEL, RING

13

6732-21-1930

SEAL, O-RING

14

6732-21-6160

PLUG, EXPANSION

15

6732-21-5530

PLUG, EXPANSION

16

6732-11-1920

PLUG, PIPE

17

6732-11-1910

PLUG, PIPE

|$22

6732-21-1960

PLUG, THREADED

18

NSS

PLUG, THREADED

19

6215-81-9710

SEAL, O-RING

N/I

6215-81-9710

SEAL, O-RING

20

6736-29-2110

SLEEVE, SALVAGE
