Запчасти Komatsu WB150WSC-2 ЗАДН. МОСТ (/) РАМА

Схема запчастей Komatsu WB150WSC-2 - ЗАДН. МОСТ (/) РАМА
1
25
24
2
23
3
22
4
5
24
3
5
19
3
22
8
5
6
7
6
3
21
20
9
18
19
2
10
11
12
13
16
14
17
15

Артикул

Название

Примечание

Количество

\0

200040651

REAR AXLE, ASSY

1

CA0021558

PLUG

2

CA0145532

BEAM TRUMPET

3

CA0028562

O-RING

4

CA0140473

BRAKE CYLINDER, L.H.

5

CA0125280

PLUG

6

CA0028111

O-RING

7

CA0143287

CENTRAL BODY

8

CA0140472

BRAKE CYLINDER, R.H.

9

CA0137474

BREATHER

10

CA0128632

BELLEVILLE WASHER

11

CA0144558

BUSH

12

CA0116962

BUSH

13

CA0145761

SEAL RING

14

CA0027693

SPHERICAL BEARING

15

CA0128631

BELLEVILLE WASHER

16

CA0021334

BOLT

17

CA0021364

BOLT

18

CA0121618

BREATHER SUPPORT

19

CA0092270

PLUG

20

CA0139147

STUD

21

CA0022128

NUT

22

CA0116792

BREATHER

23

CA0143296

OIL TUBE

24

CA0023273

WASHER

25

CA0021397

SCREW

Выбрано товаров: 26
