Запчасти Komatsu WB150WSC-2 РУКОЯТЬ И КОВШ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

312709051

ARM

2

500217002

BUSHING

3

500217005

BUSHING

4

860010007

FITTING

5

802610118

COTTER

6

312710052

PIN

7

500217008

BUSHING

8

801105159

BOLT

9

801880212

SELF-LOCKING NUT

10

500270024

SPACER

11

390597064

PIN

12

802610118

COTTER

13

312312078

BUCKET L=600 MM

13

312312079

BUCKET L=500 MM (OPTIONAL)

13

312312080

BUCKET L=400 MM (OPTIONAL)

13

312312081

BUCKET L=300 MM (OPTIONAL)

13

312312082

BUCKET L=700 MM (OPTIONAL)

13

312312083

BUCKET L=800 MM (OPTIONAL)

13

312312084

BUCKET L=900 MM (OPTIONAL)

14

200323390

PIN

15

312204054

TOOTH

16

801580085

BOLT

17

801703012

NUT

18

312204053

TOOTH

19

312204052

TOOTH

20

801014184

BOLT

21

802030505

RING NUT

22

802040037

WASHER

23

312710050

LEVER, R.H.

24

312710051

LEVER, L.H.

25

500250056

SPACER

26

200703069

LEVER
