Запчасти Komatsu WB150WSC-2 УПРАВЛ-Е ПОГРУЗ. КОВШОМ КЛАПАН (С ВОЗВРАТ В РАБОЧ. ПОЛОЖ-Е) (ДЛЯ КОВША [4 В 1]) (/) ГИДРАВЛИКА РАБОЧЕЕ ОБОРУДОВАНИЕ

\0

844020280

SHOVEL CONTROL VALVE, ASSY.

\0

844020338

SHOVEL CONTROL VALVE, ASSY.

\0

844200495

BLOCK, SHOVEL DUMPING, ASSY.

\0

844200709

BLOCK, SHOVEL DUMPING, ASSY.

1

KIT, HOUSING

2

844200503

COMPENSATOR KIT

3

844200416

KIT, VALVE

4

844200422

SECONDARY VALVE

5

844200174

KIT, GASKET

6

844200423

LOCKING COVER KIT (ORANGE)

7

844200424

LOCKING COVER KIT (BLUE)

8

844200615

OPERATION KIT

9

844200427

BELLOWS KIT

10

844200467

KIT, FLANGE

11

844200732

KIT

12

844200504

KIT, GASKET

12

844200699

KIT, GASKET

13

844200509

KIT, GASKET

13

844200632

KIT, GASKET

14

SEAL, OIL

14

SEAL, OIL

15

O-RING

16

844200413

KIT, GASKET

17

O-RING

18

O-RING
