Запчасти Komatsu WB150WSC-2 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

312605125

OPERATOR'S CAB, ASSY.

1

312605310

CABIN STRUCTURE

2

312605681

GLASS, UPPER

3

312605680

GLASS, LOWER

4

312605682

GLASS WINDOW,L.H.

5

312605715

GLASS WINDOW,R.H.

6

816214683

DOOR, ASSY.

7

312605730

GLASS, DOOR, R.H.

8

816214589

FRAME, DOOR, R.H.

9

816214590

SEAL, DOOR, R.H.

10

816214682

DOOR, L.H., ASSY.

11

312605731

GLASS, DOOR, L.H.

12

816214591

FRAME, DOOR, L.H.

13

816214592

SEAL, DOOR, L.H.

14

816214685

WINDOWS, R.H., ASSY.

15

312605713

GLASS WINDOW,R.H.

16

816214593

FRAME,WINDOW,R.H.

17

816214594

GASKET,WINDOW,R.H.

18

816214684

LEFT WINDOW,ASSY

19

312605714

GLASS WINDOW,L.H.

20

816214595

FRAME,WINDOW,L.H.

21

816214596

GASKET,WINDOW,L.H.

22

816213300

RUBBER

23

801200700

SCREW

24

816213344

SPACER

25

802170001

SPRING WASHER

26

816214635

NUT

27

801920051

COVER

28

816214970

GASKET

29

816214669

FRAME + GLASS,ASSY

30

312605687

GLASS, DOOR

31

312605686

FRAME, DOOR

32

816214600

GASKET, UPPER

33

816214601

GASKET, LATERAL

34

816214598

GASKET, LOWER

35

816214603

PLUG,FRAME,R.H.

36

816214604

PLUG,FRAME,L.H.

37

878000333

KIT, SIZING

38

816215102

SHIM

39

312605692

GLASS, LOWER
