Запчасти Komatsu WB150PS-2N FIG. H-PA PPC УПРАВЛ-ЕS - ЭКСКАВАТ. РУКОЯТЬ SECTION ГИДРАВЛИКА

|$4

844020736

ARM SECTION

1

NSS

HOUSING AND SPOOL

|$6

844200503

COMPENSATOR KIT

2

NSS

SPOOL

3

NSS

POPPET

4

NSS

PLUG WITH O-RING

|$10

844200416

LOAD CHECK VALVE KIT

5

NSS

POPPET

6

NSS

SPRING, RETURN

7

NSS

PLUG WITH O-RING

|$14

844200725

OPERATING KIT

8

NSS

BOLT

9

NSS

COVER, END

10

NSS

O-RING

11

NSS

SPRING, RETURN

12

NSS

RETAINER, SPRING

|$20

844200422

VALVE, CIRCUIT RELIEF

13

NSS

VALVE, RELIEF

14

844200174

SEAL KIT

|$23

844200441

PLUG, PORT

15

NSS

PLUG

16

844200174

SEAL KIT

17

844200424

LOCK COVER KITBLUE

|$27

844200423

LOCK COVER KITORANGE

18

844200504

GASKET KIT

19

844200413

GASKET KIT

20

NSS

O-RING

21

NSS

O-RING

22

NSS

O-RING
