Запчасти Komatsu WB150PS-2N FIG. H-A КОНТРОЛЬНЫЙ КЛАПАН РАБОЧ. ОБОРУДОВАНИЯ - СТРЕЛА SECTION - MP КОВШ ГИДРАВЛИКА

|$1

844200711

BOOM SECTION

1

NSS

HOUSING

|$3

844200503

COMPENSATOR KIT

2

NSS

SPOOL

3

NSS

POPPET

4

NSS

PLUG, END

|$7

844200416

LOAD CHECK VALVE KIT

5

NSS

POPPET

6

NSS

SPRING, RETURN

7

NSS

PLUG, END

|$11

844200615

OPERATING KIT

8

NSS

EYE, SPOOL

|$13

844200427

BELLOWS KIT

9

NSS

BELLOWS

10

NSS

BOLT

11

NSS

PLATE, OUTER

12

NSS

PLATE, INNER

13

NSS

SEAL, SPOOL

|$19

844200698

COVER KIT

14

NSS

RETAINER, SEAL

15

NSS

SEAL, SPOOL

16

NSS

COVER, LOWER

17

NSS

RETAINER, SEAL

18

NSS

SPRING, RETURN

19

NSS

PLATE, RETAINER

20

NSS

HOUSING, DETENT

21

NSS

BALL, DETENT

22

NSS

SPRING, RETURN

23

NSS

BALL, ACTUATOR

24

NSS

HOUSING, CATCH

25

NSS

COVER, END

26

NSS

BOLT

27

844200699

GASKET KIT

28

844200632

GASKET KIT

29

844200413

SEAL KIT, BETWEEN SECTIONS
