Запчасти Komatsu WB150PS-2N FIG. T7-A ПОГРУЗ. КОВШ И РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

312602052

ARM

2

390661002

BUSHING

3

500211029

BUSHING

4

390658012

BUSHING

5

860010007

FITTING, GREASE

6

312601665

PIN, ARM

7

390608003

SHIM (3 MM)

8

390608006

SHIM (1 MM)

9

802270019

RING, SNAP

10

801015584

BOLT

11

801880212

NUT, SELF-LOCKING

12

312602600

LEVER

13

312602613

PIN, ARM/LEVER

14

390608002

SHIM (3 MM)

|$14

390608005

SHIM (1 MM)

15

802270017

RING, SNAP

16

860010007

FITTING, GREASE

17

312602612

LEVER, BUCKET

18

390661003

BUSHING

19

500211029

BUSHING

20

312602620

PIN, LEVER

21

801015700

BOLT

22

390605090

WASHER

23

801880224

NUT

24

WB14001FY

BUCKET (CUTTING EDGE)

|$28

WB14001ZY

BUCKET (NO CUTTING EDGE)

|$29

12F-70-31251

CUTTING EDGE FOR BUCKET

|$33

02090-11055

BOLT

|$37

02290-11016

NUT

|$41

20X-70-14151

ADAPTER

|$42

20X-70-14160

TOOTH

|$43

20X-70-14170

PIN

|$44

20X-70-14180

LOCK, PIN

25

312604609

PIN, ARM/LEVER TO BUCKET

26

801015583

BOLT

27

801880212

NUT, SELF-LOCKING

28

860010007

FITTING, GREASE

29

NSS

TOOTH

30

NSS

BOLT

31

NSS

NUT
