Запчасти Komatsu WB150PS-2N FIG. M-A КАПОТ ЧАСТИ КОРПУСА

1

312605139

HOOD (CABIN)

1

312605140

HOOD (CANOPY)

2

312648656

SCREEN, GRILL

3

801370016

BOLT

4

802148003

WASHER

5

855711099

GASKET, HOOD

6

802620095

PIN, COTTER

7

3F0540602

BOOT

8

816214346

LOCK, HOOD

9

801200697

SCREW

10

801880208

NUT

11

816214962

LOCK ASSEMBLY

12

801920103

NUT

13

801014049

BOLT

14

312605084

PORT, INSPECTION

15

801015110

BOLT

16

801852210

NUT, SELF-LOCKING

17

804010058

WASHER, SPRING

18

312605757

GASKET

19

816214960

LOCK

20

312605696

GUIDE, HOOD ALIGNING (FORMED)

21

801015086

BOLT

22

802170001

WASHER

23

312601065

LINKAGE, HINGE

24

805630100

BEARING/SPACER

25

801880212

NUT, SELF-LOCKING

26

802170003

WASHER

27

312648726

LEVER, L.H.

28

312648727

LEVER, R.H.

29

802070020

WASHER

30

802620102

PIN, COTTER

31

801015110

BOLT

32

802170002

WASHER

33

816214872

CYLINDER

34

801015089

BOLT

35

801920104

NUT

36

802170001

WASHER

37

312648657

SUPPORT

38

801200017

SCREW
