Запчасти Komatsu WB150PS-2N FIG. A-A ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ

Схема запчастей Komatsu WB150PS-2N - FIG. A-A ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ
33
28
31
19
28
31
28
59
31
28
58
57
32
58
44
17
28
59
15
18
13
41
6
10
58
58
30
57
12
5
41
45
4
3
24
14
26
56
22
2
52
25
13
6
53
1
34
22
35
24
47
13
42
20
9
7
46
50
55
54
48
52
21
51
49
22
23
13
29
43

Артикул

Название

Примечание

Количество

1

YM119000-55600

FILTER

2

YM129470-55610

BODY, FUEL FILTER

3

YM194180-51640

SPACER

4

YM26106-100252

BOLT

5

YM26450-100302

BOLT

6

YM101304-59020

JOINT

7

YM129957-59040

PIPE

9

YM119560-59110

PROTECTOR

10

YM129957-59040

PIPE

12

YM119560-59110

PROTECTOR

13

YM124766-59050

CLAMP

14

YM121750-59890

TIE STRAP

15

YM121855-59111

BOLT

17

YM124060-59380

PLUG

18

YM22190-060002

GASKET

19

YM121855-59880

JOINT

20

YM121855-59880

JOINT

21

YM119006-59880

JOINT

22

YM22190-120002

GASKET

23

YM23857-060000

BOLT

24

YM124766-59050

CLAMP

25

YM129957-59050

PIPE

26

YM129957-59120

PROTECTOR

28

YM124066-59100

CLAMP

29

YM129495-59300

BOLT

30

YM129980-59530

JOINT

31

YM121250-59550

PIPE

32

YM124732-59562

PIPE

33

YM129150-59580

CAP

34

YM121855-59880

JOINT

35

YM128300-59910

VALVE

41

YM22190-140002

GASKET

42

YM22190-140002

GASKET

43

YM23414-080000

GASKET

44

YM26106-080102

BOLT

45

YM120324-55750

SEPARATOR

46

YM120324-55760

ELEMENT, FUEL OIL

47

YMX0582810173

GASKET

48

YMX0580121073

O-RING

49

YMX0311121522

BOLT, CENTER

50

YMX0300120414

GASKET

51

YMX0313080110

BOLT

52

YMX0588080273

GASKET

53

YMX2740134001

COVER

54

YMX2540025002

CASE ASSEMBLY

55

YMX0600160122

SPRING

56

YMX0314080110

PLUG

57

YM124750-59910

JOINT

58

YM22190-140002

GASKET

59

YM23857-080000

JOINT

Выбрано товаров: 50
