Запчасти Komatsu WB150AWS-2N FIG. A-A TIER I ДВИГАТЕЛЬ - STARTER ДВИГАТЕЛЬ

|$1

YM12995377010

MOTOR, STARTER

|$2

YM12125477402

ARMATURE

1

NSS

BEARING, FRONT

2

NSS

ARMATURE

3

NSS

WASHER, BEARING

4

NSS

BEARING, REAR

|$7

YM12125477430

THRUST WASHER KIT

5

NSS

WASHER, THRUST

6

NSS

WASHER, THRUST

|$10

YM12125477480

PINION STOP KIT

7

NSS

STOP, PINION

8

NSS

RING, RETAINING

|$13

YM12125477521

FIELD COIL

9

YM12125477541

BRUSH

10

NSS

SCREW

11

NSS

HOUSING, COIL

12

NSS

COIL, FIELD

13

YM12125477550

COVER

|$19

YM12125477571

BRUSH HOLDER

14

YM12125477581

BRUSH

15

YM12125477590

SPRING

16

NSS

HOLDER

|$23

YM12125477600

CENTER BEARING HOUSING

17

YM12125477610

SEAL, OIL

18

YM12125477620

BEARING, NEEDLE

19

NSS

HOUSING, CENTER

|$27

YM12125477640

GEAR SHAFT

20

NSS

SHAFT, GEAR

21

NSS

PLATE, BACKING

|$30

YMX2130570040

SOLENOID SWITCH

22

NSS

PLUNGER, SWITCH

23

NSS

SPRING, RETURN

24

NSS

SWITCH, SOLENOID

|$34

YM12125477681

GEAR CASE

25

NSS

CASE, GEAR

26

YM12125477690

BUSHING, GEAR CASE

|$37

YM12125477700

SHIFT LEVER KIT

27

NSS

LEVER, SHIFT

28

NSS

BOLT, LEVER

29

NSS

WASHER

30

NSS

NUT

|$42

YM12125477730

DUST COVER KIT

31

NSS

COVER

32

NSS

COVER

33

NSS

COVER

34

YM12125477770

BOLT

35

YM12125477790

SCREW

36

YM12125477810

COVER, TERMINAL

37

YM26106060302

BOLT

38

YM26106060452

BOLT

39

YM12125477780

SCREW

40

YM12995377660

PINION
