Запчасти Komatsu WB150AWS-2N FIG. T-A M МОЛОТ - INTERNAL ЧАСТИ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

827010270

PLUG

2

827010263

SCREW

3

827010264

RING

4

827010421

CAP, UPPER

5

827010278

SCREW

6

827010276

MEMBRANE

7

827010420

CAP, LOWER

8

827010277

BOLT

9

827010274

ROD, TIE

10

827010413

HEAD

11

827010418

DIAPHRAGM, ABSORBER

12

827010417

COVER, ABSORBER

13

827010419

PIN, ALIGNING

14

827010414

HOUSING

15

827010416

DISTRIBUTOR

16

827010380

PIN, ALIGNING

17

827010412

REDUCTION

18

827010356

PISTON

19

827010411

VALVE

20

827010409

CYLINDER

21

827010408

BUSHING

22

827010271

RETAINER

23

827010388

LINKAGE

24

827010393

SCREW

25

827010390

PLUG

26

827010389

GASKET

27

827010391

UNION

28

827010366

WASHER

29

827010392

SNAP RING

30

827010395

CYLINDER

31

827010397

PISTON

32

827010398

SPRING

33

827010400

SPACER, CYLINDER

34

827010261

SHIM

35

827010401

PLUG

36

827010361

BLOCK

37

827010275

NUT

38

827010258

SPRING

39

827010272

PLUG

40

827010406

BUSHING, LOWER

41

827010371

PIN

42

827010254

FITTING, GREASE

43

827010273

PIN, SPLIT

44

827010424

SEAL KIT

45

NSS

RING, SEAL

46

NSS

SEAL, RING

47

NSS

O-RING

48

NSS

O-RING

49

NSS

O-RING

50

NSS

RING, SEAL

51

NSS

SEAL, RING
