Запчасти Komatsu WB150AWS-2N FIG. T-A M МОЛОТ - INTERNAL ЧАСТИ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

827010369

PIN, SPLIT

2

827010263

SCREW

3

827010264

RING

4

827010266

SCREW

5

827010403

CAP, UPPER

6

827010262

MEMBRANE

7

827010402

CAP, LOWER

8

827010265

BOLT

9

827010381

HEAD

10

827010386

DIAPHRAGM, ABSORBER

11

827010385

COVER, ABSORBER

12

827010382

HOUSING

13

827010384

DISTRIBUTOR

14

827010380

PIN, ALIGNING

15

827010379

REDUCTION

16

827010342

PISTON

17

827010378

VALVE

18

827010341

CYLINDER

19

827010259

ROD, TIE

20

827010376

BUSHING

21

827010374

BLOCK

22

827010254

FITTING, GREASE

23

827010260

NUT

24

827010371

PIN, SPLIT

25

827010375

BUSHING, LOWER

26

827010370

RETAINER

27

827010388

LINKAGE

28

827010393

SCREW

29

827010390

PLUG

30

827010389

GASKET

31

827010391

UNION

32

827010366

WASHER

33

827010392

SNAP RING

34

827010395

CYLINDER

35

827010397

PISTON

36

827010398

SPRING

37

827010400

SPACER, CYLINDER

38

827010261

SHIM

39

827010401

PLUG

40

827010424

SEAL KIT

41

NSS

RING, SEAL

42

NSS

SEAL, RING

43

NSS

O-RING

44

NSS

O-RING

45

NSS

O-RING

46

NSS

RING, SEAL

47

NSS

SEAL, RING

48

NSS

O-RING
