Запчасти Komatsu WB150AWS-2N FIG. K7-A КОНДИЦ. ВОЗДУХА - COMPLETE БЛОК КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

888011121

AIR CONDITIONER

|$1

888011122

CAB KIT

1

312649121

ENCLOSURE, HEATER CORE

2

801105546

BOLT

3

802170002

WASHER, SPRING

4

888011052

PANEL, HOSE CONNECTION

5

NSS

BOLT

6

NSS

WASHER

7

888011053

UNION

8

312649122

EVAPORATOR CORE

9

312649154

ENCLOSURE, EVAPORATOR

10

NSS

BOLT

11

NSS

WASHER

12

312649606

FLANGE

13

801104042

SCREW

14

855021013

O-RING

15

855021015

O-RING

16

312649074

VALVE

17

312649125

GASKET

18

888011061

HOLDER, THERMOSTAT

19

NSS

BOLT

20

NSS

WASHER

21

312649076

THERMOSTAT

22

312649083

WIRING HARNESS

23

NSS

GROMMET, RUBBER

24

888011054

GASKET, ADHESIVE

25

888011048

CORE, HEATER

26

312649123

ENCLOSURE, HEATER CORE

27

312649082

BLOWER, HEATER

28

312649075

RESISTOR

29

NSS

BOLT

30

NSS

NUT

31

312649137

BRACKET, RESISTOR SUPPORT

32

NSS

BOLT

33

312632603

BRACKET, SUPPORT
