Запчасти Komatsu WB150AWS-2N FIG. K9-A КАБИНА - FOUR РАБОЧ. ОСВЕЩЕНИЕ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$1

885111114

LEFT WORK LIGHT

1

885140049

BULB

2

NSS

HOUSING, LIGHT

3

NSS

WASHER, MOUNTING

|$5

885111113

RIGHT WORK LIGHT

|$6

885140049

BULB

|$7

NSS

HOUSING, LIGHT

|$8

NSS

WASHER, MOUNTING

4

801105525

BOLT

5

802170000

WASHER

6

802120006

WASHER, SPRING

7

816214659

NUT, LOCK

8

312612168

BRACKET LEFT FRONT

|$14

312612167

BRACKET RIGHT FRONT

9

312612627

PLATE

10

801852208

NUT, LOCK

11

801920051

COVER, NUT

12

312612168

BRACKET, LEFT REAR

|$19

312612167

BRACKET, RIGHT REAR

13

312612629

GASKET

14

01598-00809

NUT, LOCK

|$22

885111120

LEFT RED LIGHT

15

885140017

BULB

16

NSS

HOUSING, LIGHT

|$25

885111119

RIGHT RED LIGHT

|$26

885140017

BULB

|$27

NSS

HOUSING, LIGHT

|$28

885111122

LEFT ORANGE LIGHT

17

885140016

BULB

18

NSS

HOUSING, LIGHT

|$31

885111121

RIGHT ORANGE LIGHT

|$32

885140016

BULB

|$33

NSS

HOUSING, LIGHT
