Запчасти Komatsu WB150AWS-2N FIG. H-A ЭКСКАВАТ. КЛАПАН - ОПОРА SECTION ГИДРАВЛИКА

|$4

844200703

OUTRIGGER SECTION

1

NSS

HOUSING AND SPOOL

|$6

844200503

COMPENSATOR KIT

2

NSS

SPOOL

3

NSS

POPPET

4

NSS

PLUG, END

|$10

844200416

LOAD CHECK VALVE KIT

5

NSS

POPPET

6

NSS

SPRING, RETURN

7

NSS

PLUG, END

|$14

844200615

OPERATING KIT

8

NSS

EYE, SPOOL

|$16

844200427

BELLOWS KIT

9

NSS

BELLOWS

10

NSS

BOLT

11

NSS

PLATE, OUTER

12

NSS

PLATE, INNER

13

NSS

SEAL, SPOOL

|$22

844200425

COVER KIT

14

NSS

SEAL, SPOOL

15

NSS

RETAINER, SEAL

16

NSS

RETAINER, SPRING

17

NSS

SPRING, RETURN

18

NSS

BOLT, RETAINER

19

NSS

COVER, END

20

NSS

BOLT

21

844200699

SEAL KIT

22

844200632

SEAL KIT

23

844200413

SEAL KIT
