Запчасти Komatsu WB150AWS-2N FIG. F-A ТРАНСМИССИЯ - WD МУФТА СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

1

CA0138399

BELLEVILLE WASHER

2

CA0138394

SPACER

3

CA0138391

THRUST WASHER

4

CA0106866

SHIM 01 MM

|$5

CA0106867

SHIM 03 MM

|$6

CA0106868

SHIM 05 MM

5

CA0024799

SNAP RING

6

CA0025809

BEARING

7

CA0028528

O-RING

8

CA0139343

FRONT COVER

9

CA0020852

BOLT

10

CA0025485

OIL SEAL

11

CA0139344

FRONT FLANGE

12

CA0028131

O-RING

13

CA0129924

WASHER

14

CA0123918

BOLT

15

CA0028624

O-RING

16

CA0139341

CLUTCH PISTON

17

CA0028548

O-RING

18

CA0139338

OUTPUT SHAFT

19

CA0021558

PLUG

20

CA0138787

SEAL RING

21

CA0139342

PIN

22

CA0028534

O-RING

23

CA0138384

BRAKE PLATE

24

CA0141113

DRIVE PLATE

25

CA0141112

DISC PLATE

26

CA0025009

LOCK RING

27

CA0141114

LOCK RING

28

CA0139339

GEAR

29

CA0024780

SNAP RING

30

CA0025818

BEARING

31

CA0026190

BEARING

32

CA0138395

SPACER

33

CA0027534

BEARING

34

CA0028623

THRUST WASHER

35

CA0138397

REAR FLANGE

36

CA0020852

BOLT

37

CA0133373

REAR COVER
