Запчасти Komatsu WB150AWS-2N FIG. F-A ТРАНСМИССИЯ - 1, 3, И 4 ПРИВОД МУФТАES СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

1

CA0028041

NEEDLE BEARING

2

CA0139389

SPEEDOMETER DISC

3

CA0025809

BEARING

4

CA0082020

SHIM 01 MM

|$5

CA0082021

SHIM 03 MM

|$6

CA0082022

SHIM 05 MM

5

CA0125829

WASHER

6

CA0025053

LOCK RING

7

CA0133980

DRIVE PLATE

8

CA0138574

DISC PLATE

9

CA0025067

LOCK RING

10

CA0140332

LOCK RING

11

CA0138368

GEAR

12

CA0129901

TRUST WASHER

13

CA0025031

LOCK RING

14

CA0133912

SPRING COVER

15

CA0129896

SPRING

16

CA0140126

CLUTCH PISON

17

CA0138790

SEAL RING

18

CA0138786

SEAL RING

19

CA0021558

PLUG

20

CA0028372

ROLLER

21

CA0024321

SPLIT PIN

22

CA0139392

SHAFT

23

CA0138366

GEAR

24

CA0025066

LOCK RING

25

CA0138365

GEAR

26

CA0138381

LOCK RING

27

CA0138377

DRIVE PLATE

28

CA0138378

DISC PLATE

29

CA0139348

SPRING

30

CA0139347

SPRING COVER

31

CA0025021

LOCK RING

32

CA0140141

CLUTCH PISTON

33

CA0138372

SEAL RING

34

CA0028015

NEEDLE BEARING

35

CA0137825

SEAL RING

36

CA0138369

GEAR

37

CA0133379

SPACER

38

CA0028350

BUSH

39

CA0138364

SEAL RING

40

CA0138398

COVER

41

CA0020852

BOLT

42

CA0024799

SNAP RING

43

CA0079175

THRUST WASHER

44

CA0026190

BEARING

45

CA0082020

SHIM 01 MM

|$48

CA0082021

SHIM 03 MM

|$49

CA0082022

SHIM 05 MM

46

CA0140117

BELLEVILLE WASHER

47

CA0140116

BELLEVILLE WASHER
